AIM Mychron 6 2T Pre-Order
PRE-ORDER ONLY – STOCK DUE: TBA
Advanced Lap Timing and Data Analysis
The AiM MyChron 6 2T is a versatile GPS lap timer designed for karting, offering reliable performance monitoring and enhanced data capabilities. With 25 Hz GPS tracking, dual temperature inputs, and a user-friendly interface, it’s a dependable tool for racers seeking to optimise their track performance.
Key Features
- 8 Configurable RGB Backlight Colours
- 5 RGB Shift Lights and 2 RGB Alarm LEDs
- 2 Temperature Inputs
- Lap Timing via GPS, Magnet Sensor, or Infrared
- RPM Input
- 4 GB Memory – Over 3000 Hours of Data
- Wi-Fi and Bluetooth Connectivity (for Heart Rate Monitors)
- Rechargeable Lithium Battery (Up to 20 Hours)
- Two CAN Connections for AiM Expansions & ECU
- USB-C for Data Transfer, Memory, and Charging
- Integrated 6-Axis Inertial Platform
- Programmable Digital Output for High/Low Activation
Why Consider the MyChron 6 2T Lap Timer?
The MyChron 6 2T Lap Timer builds on the features of the previous generation, offering dual water temperature sensor inputs, expanded data logging, and an intuitive interface. With precise lap timing and the ability to monitor water temperature from two sources, the MyChron 6 2T provides a robust platform for trackside performance analysis.
Dual Temperature Sensor Inputs:
The MyChron 6 2T includes two temperature sensor inputs. The optional second sensor can be connected via the included dual/splitter patch lead, allowing simultaneous monitoring of two temperature sources. Additional configurations can be achieved with alternative leads or by using the MyChron Expansion Module.
Lap Times & Data Analysis
Equipped with a 25 Hz GPS chipset, the MyChron 6 2T offers accurate lap timing and position data. It helps analyse racing lines, cornering speeds, and braking points via the free Race Studio 3 software. Future mobile app integration for iPhone and Android is also planned.
Data transfer is seamless using built-in Wi-Fi or a USB-C connection, ensuring quick access to your performance data.
Display & LED System
The high-resolution display with adjustable RGB backlight ensures excellent readability in all lighting conditions. Drivers can track best vs current sector times in real-time, making adjustments to improve delta times on the go.
The 5 configurable RGB shift lights can display delta lap times or act as traditional shift indicators, while 2 RGB alarm LEDs monitor two temperature inputs simultaneously, ensuring optimal engine performance and preventing damage from overheating.
Rechargeable Battery
The MyChron 6 2T is powered by a rechargeable lithium battery, providing up to 20 hours of runtime. It can be recharged using the included USB Type-C cable.
Performance Insights
The integrated 6-axis inertial platform delivers valuable insights into kart dynamics, including steering input analysis to identify oversteer and understeer. This allows for precise setup adjustments to enhance track performance.
Analyse with Race Studio 3
Using Race Studio 3, you can download and analyse data from the MyChron 6 2T on your PC. Graphs, histograms, and tables provide detailed insights into your performance, helping you refine your driving and avoid costly mistakes.
Compatible Expansions
The MyChron 6 2T is compatible with various expansions and modules, including:
- SmartyCam 3 Cameras
- IR Temperature Controller
- MyChron Expansion
- Lambda Modules (LCU-One and LCU-One S)
PRE-ORDER ONLY – STOCK DUE: TBA
The AiM MyChron 6 2T offers dependable data monitoring and analysis, supporting racers at all levels. Secure your pre-order now.
