Freeline Gearbox Tie Rod 470mm Assembly 10.2586.00
SKU:FL-10-2586-00-NE
Sale
Sold out
£47.90
Ex VAT:
£21.69
£26.03
Inc VAT
Shipping calculated at checkout.
Only 2 units left
Couldn't load pickup availability
Part of the Freeline Brake Tie Rods A diagram
See the other 5 parts in this group · add what else you need
View all 6 in Freeline Brake Tie Rods A →Browse the full Freeline / Birel ART diagram →
View the Freeline Brake Tie Rods A parts diagram →Numbered drawing · find your part and add it from the listLoading parts…
| Pos. | FREELINE PART NUMBER | KKC SKU | Description | RRP |
|---|---|---|---|---|
| 1 | 10.17144.00 | FL-10.17144.00 | BRAKE BALANCE ASSEMBLY | 80.0 |
| 2 | 20.1151.06 | FL-20-1151-06 | TIE ROD FORK | 5.45 |
| 3 | 40.16548.00 | FL-40.16548.00 | SPRING PRESSURE 5X12 | 4.0 |
| 4 | 20.16544.06 | FL-20.16544.06 | NUT M10X1 BRAKE DISTRIBUTOR | 6.4 |
| 5 | 40.13251.00 | FL-40.13251.00 | BALL JOINT M6 | 14.83 |
| 6 | 20.16673.06 | FL-20.16673.06 | UNIBALL SPACER M6 | 2.5 |
| 7 | 20.16543.06 | FL-20.16543.06 | PIN M10X1 BRAKE TIE ROD | 5.4 |
| 8 | 10.17572.00-NE | FL-10.17572.00-NE | KNOB BRAKE ADJUST, ASSY. | 3.25 |
| 9 | 20.1946.06 | FL-20-1946-06 | SHAPED NUT M6 RIGHT | 2.48 |
| 10 | 20.11896.06 | FL-20-11896-06 | TIE ROD L=300 | 8.02 |
| 10 | 20.12625.06 | FL-20-12625-06 | TIE ROD L=340 | 8.02 |
| 11 | 20.11329.06 | FL-20-11329-06 | BRAKE TIE ROD 6X98.5 | 12.33 |
| 12 | 20.15055.06 | FL-20.15055.06 | PIN TC 5X13.5 | 1.5 |
| 13 | 40.7072.00 | FL-40-7072-00 | WASHER 5x9x0,5 | 0.63 |
| 14 | 40.5182.00 | FL-40-5182-00 | SPLIT PIN 1,5x12 UNI 1336 | 0.63 |
Parts diagram
About this Product
FREELINE GEARBOX TIE ROD 470 ASSEMBLY
