Freeline Adjustable Pedal Pin Mini
SKU:FL-20-16100-10-NE
Sale
Sold out
Ex VAT:
£16.90
£20.28
Inc VAT
Shipping calculated at checkout.
Only 2 units left
Couldn't load pickup availability
Part of the Freeline Pedals Hi Tech diagram
See the other 8 parts in this group · add what else you need
View all 9 in Freeline Pedals Hi Tech →Browse the full Freeline / Birel ART diagram →
View the Freeline Pedals Hi Tech parts diagram →Numbered drawing · find your part and add it from the listLoading parts…
| Pos. | FREELINE PART NUMBER | KKC SKU | Description | RRP |
|---|---|---|---|---|
| 1 | 10.15586.00-NE-BA | FL-10-15586-00-NE-BA | GAS PEDAL ADJUSTABLE, ASSY. | 109.61 |
| 1 | 10.15586.00-NE-BA | FL-10-15586-00-NE-BA | GAS PEDAL ADJUSTABLE, ASSY. | 109.61 |
| 2 | 10.15588.00-NE-BA | FL-10-15588-00-NE-BA | BRAKE PEDAL ADJUSTABLE, ASSY. | 109.61 |
| 2 | 10.15588.00-NE-BA | FL-10-15588-00-NE-BA | BRAKE PEDAL ADJUSTABLE, ASSY. | 109.61 |
| 3 | 20.15657.10-NE | FL-20-15657-10-NE | ADJUSTABLE PEDAL, BARE | 52.72 |
| 4 | 20.15574.10-NE | FL-20-15574-10-NE | ADJUSTABLE PEDAL PIN | 21.57 |
| 4 | 20.15574.10-NE | FL-20-15574-10-NE | ADJUSTABLE PEDAL PIN | 21.57 |
| 5 | 20.15587.06 | FL-20-15587-06 | SCREW VTB M8x75 USA | 4.94 |
| 6 | 20.15720.06 | FL-20-15720-06 | ACCELERATOR PEDAL SPRING ADJUSTABLE | 3.35 |
| 7 | 20.15576.06 | FL-20-15576-06 | ADJUSTABLE PEDAL BUSHING | 6.41 |
| 8 | 20.15643.10-LU | FL-20-15643-10-LU | PIN PEDAL STOP SCREW | 8.14 |
| 9 | 20.12698.18-NE | FL-20-12698-18-NE | HEADCOVER STOP SCREW FOR PEDALS | 1.86 |
| 10 | 40.0217.00 | FL-40-0217-00 | CIRCLIP 3,1x11x1 | 0.63 |
| 11 | 20.15719.06 | FL-20-15719-06 | BRAKE PEDAL SPRING ADJUSTABLE | 3.35 |
| 12 | 10.16101.00-NE-BA | FL-10-16101-00-NE | GAS PEDAL ADJUSTABLE MINI, ASSY. | 95.02 |
| 12 | 10.16101.00-NE-BA | FL-10-16101-00-NE | GAS PEDAL ADJUSTABLE MINI, ASSY. | 95.02 |
| 13 | 10.16102.00-NE-BA | FL-10-16102-00-NE | BRAKE PEDAL ADJUSTABLE MINI, ASSY. | 95.02 |
| 13 | 10.16102.00-NE-BA | FL-10-16102-00-NE | BRAKE PEDAL ADJUSTABLE MINI, ASSY. | 95.02 |
| 14 | 20.16099.10-NE | FL-20.16099.10-NE | ADJUSTABLE PEDAL MINI, BARE | 52.72 |
| 15 | 20.16100.10-NE | FL-20-16100-10-NE | ADJUSTABLE PEDAL PIN MINI | 16.9 |
| 16 | 10.10431.00 | FL-10-10431-00 | ACCELERATOR CABLE KIT | 16.03 |
| 16 | 10.12527.00 | FL-10-12527-00 | CLUTCH CONTROL KIT | 16.03 |
| 16 | 10.4792.00 | FL-10-4792-00 | CABLE SAFETY KIT | 8.02 |
Parts diagram
About this Product
Component Type: Hi-tech pedal pin / pivot bolt.
Application: Designed specifically for the Mini kart / youth chassis lineup (e.g., Charles Leclerc / Birel ART mini karts).
Function: Serves as the pivot point or positioning pin for the adjustable accelerator or brake pedal assemblies, allowing smaller drivers to reach the controls comfortably.
